Z8103AX-D – Long-Range WiFi 6 Mesh Router for Warehouse and Open Office, 6 High-Gain Antenna AX2975 Gigabit

Name: Z8103AX-D – Long-Range WiFi 6 Mesh Router for Warehouse and Open Office, 6 High-Gain Antenna AX2975 Gigabit
Brand: Zbtlink Online Store
Price: 999.00 USD
Availability: InStock

WiFi 6 AX3000 Dual-Band: 600Mbps @ 2.4GHz + 2400Mbps @ 5.8GHz, up to 128 concurrent clients

Dual-Core 1.3GHz + 256MB RAM: ARM Cortex-A53 for smooth 4K streaming, gaming & smart home management

6× External High-Gain Antennas: Wider coverage and stronger signal vs. Z8103AX-E's 4 antennas

1× GbE WAN + 3× GbE LAN: Full Gigabit wired connectivity for all devices

Enterprise Software: VPN, cloud management, parental control, WAN failover, SSID hidden built-in

Category	Specifications
CPU	ARM Cortex-A53 Dual-Core, up to 1.3GHz
Interface	1 × 10/100/1000 Mbps WAN Port 3 × 10/100/1000 Mbps LAN Ports
Button	Reset Button
External Power Supply	Input: 100–240V~ 50/60Hz 0.6A Output: 12VDC 1A
Environment	Operating Temperature: 0°C~40°C (32°F~104°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Antenna	6 × External High-Gain Antennas

WhatsApp Contact

View details

Software Features

Category	Specifications
Wireless Standards	IEEE 802.11a/n/ac/ax (5 GHz) IEEE 802.11b/g/n/ac/ax (2.4 GHz)
Frequency	2.4 GHz & 5.8 GHz (Dual-Band)
Signal Rate	600 Mbps @ 2.4 GHz 2400 Mbps @ 5.8 GHz
Max. Associated Clients	128
WAN Failover	Supported
Wireless Security	WPA / WPA2 / WPA-PSK
Software Features	Channel & Power Adjustment Parental Control SSID Hidden Blacklist Cloud Management NTP / DHCP VPN Support
