Z8806BE-S MT7988AV

MT7988AV Chipset:
ARM Cortex-A73 Quad-core 1.8GHz with tri-band NIC support (MT7996AV / MT7976CN / MT7977BN / MT7977AN) for Wi-Fi 7.

Wi-Fi 7 Technology:
IEEE 802.11n/g/b/a/ac/ax/be, delivering up to 19,000Mbps across 2.4G, 5.8G, and 6G bands.

Multi-Gigabit Ports:
1×2.5Gbps WAN, 1×2.5Gbps LAN, 2×1Gbps LAN, and 1×USB 2.0 for high-bandwidth connectivity.

Dual 5G & Dual SIM:
2×M.2 slots with X72/X75 module support, 2×Nano SIM, and 8 non-detachable external antennas.
CPU MT7988AV, ARM Cortex-A73 Quad-core 1.8GHz; NIC: MT7996AV / MT7976GN / MT7977BN / MT7977AN
Wi-Fi Rate IEEE 802.11n/g/b/a/ac/ax/be, MAX 19000Mbps
FLASH / RAM 1GB DDR4, 128MB SPI NAND Flash
Interface 1×2.5Gbps WAN, 1×10G SFP, 3×1Gbps LAN, 1×USB 2.0
5G & Antenna X72 / X75, 2×M.2, 2×Nano SIM, 12×Detachable External Antenna
WhatsApp Contact
View details

General Specifications

Model Z8806BE-S
Chipset MT7988AV
CPU ARM Cortex-A73 Quad-core, 1.8GHz
Protocol IEEE 802.11n/g/b/a/ac/ax/be
5G Module X72 / X75
SIM Card Slot 2 × Nano SIM
Button 1 × Reset, 1 × Mesh

Hardware Specs

RAM 1GB DDR4
Flash 128MB SPI NAND
WAN Port 1 × 2.5Gbps
LAN Ports 1 × 2.5Gbps, 2 × 1Gbps
USB 1 × USB 2.0
DC Power DC 5.5 × 2.1MM
Module Slot 2 × M.2
Antenna 8 × External, non-detachable

Wireless & Network

Wi-Fi Rate MAX 19000Mbps
2.4G NIC MT7976CN
5.8G NIC MT7977BN
6G NIC MT7977AN
AP NIC MT7996AV
Bands 2.4G / 5.8G / 6G Tri-band

    Product Practical Operation
