ZBT 4G LTE Router | 300Mbps WiFi | MT7628NN | 1WAN+3LAN | Hardware Watchdog | Global Bands - WE5927-A

Built-in 4G Module with Global Band Support:

Quectel EC200A series (CN/EU/AU) covers LTE-FDD/TDD, WCDMA, and GSM/EDGE — one hardware platform for worldwide deployments.

Hardware Watchdog for Auto-Recovery:

Monitors system heartbeat every second; auto-restarts the full system within 15s on crash, and independently power-cycles failed 4G modules — zero manual intervention.

1×WAN + 3×LAN 100Mbps Ports:

Flexible wired connectivity for multi-device office, retail, and IoT environments.

2.4G 300Mbps WiFi with 2T2R MIMO:

Stable wireless coverage with 4 external antennas (2×WiFi + 2×4G 5dBi) for reliable signal in demanding environments.

OpenWRT Compatible:

Supports ZBT OS and OpenWRT firmware for full developer customization and enterprise integration flexibility.
Category Specifications
CPU MT7628NN, MIPS24KEc, up to 580MHz
RAM DDR2 64MB
Flash NOR Flash 8MB
Interface
  • 1 × 100Mbps WAN Port (Auto MDI/MDIX)
  • 3 × 100Mbps LAN Ports (Auto MDI/MDIX)
  • 1 × SIM Slot (SIM/USIM)
  • 1 × SD Card Slot
  • 1 × DC Power Port (5.0×2.1mm)
  • 1 × Reset Button
4G Module SMT LCC+LGA, Quectel EC200A series, supports 3G & 4G (CN/EU/AU bands)
Hardware Watchdog
  • Monitors system heartbeat every 1 second
  • Restarts entire system within 15s if no heartbeat for 120s
  • Auto power-cycles failed 4G modules independently
Antenna 2 × 2.4G 5dBi non-removable + 2 × 4G 5dBi removable omnidirectional
External Power Supply Input: 6–14V DC / Rated: 12V / 1A
Environment
  • Operating Temperature: 0℃–40℃
  • Storage Temperature: -40℃–70℃
  • Working Humidity: 10%–90% RH non-condensing
  • Storage Humidity: 5%–90% RH non-condensing
Dimensions 168.61 × 129.02 × 17.94 mm | Weight: 1.02 KG | Color: Gray
SKU: WE5927-A

Out of stock

View details

MT7628NN Chipset: MIPS24KEc architecture, up to 580MHz — proven stability for routing workloads

2.4G WiFi 300Mbps: IEEE 802.11 b/g/n with 2T2R MIMO, 20/40MHz bandwidth

Built-in 4G Module: SMT LCC+LGA interface, Quectel EC200A series supporting 3G & 4G; swappable for CN/EU/AU regional bands

1×WAN + 3×LAN 100Mbps Ports: Auto MDI/MDIX, IEEE 802.3/802.3u/802.11n/g/b

Hardware Watchdog: Auto-detects system heartbeat every 1 second; restarts entire system within 15 seconds if no heartbeat for 120 seconds

4G Module Power Control: Routing system independently controls 4G module power; auto power-cycles failed modules

1× SIM Slot: Supports SIM/USIM and 1×SD card slot

4× External Antennas: 2×2.4G 5dBi (non-removable) + 2×4G 5dBi (removable) omnidirectional
